Today’s article takes the form of a picture story…

This is a list configuration. The boxes are in order, and they’re next to each other. You can label them from 0 to 5. If you know the location of one box, you also know where the others are.

As with all analogies, there are some limitations to the concept of items stored in boxes. A Python list doesn’t store objects. Instead, it contains references to those objects. The objects are stored elsewhere. However, this box analogy will serve us well nonetheless.

In a Python context, when an element is removed from a list, all the subsequent elements are shifted one position to the left to fill the gap. This process matches the analogy of the teddy bears in boxes reasonably well and is equally time-consuming.

This structure is a linked list. This is not the same thing as a list. The sequence of boxes all lined next to each other that you saw at the beginning of this picture story represents a list. The boxes scattered around the house with a sheet of paper showing where the next box is located represent a linked list.

The references to each element in a linked list are not next to each other, as they are in a list. But each element in a linked list has a reference to the next element in the sequence.

One application of a linked list is to create a queue. In a queue, the first item in is also the first item out. If you use a list—the sequence of boxes all lined up in a row—then each time you remove the first element in the list, you’ll have to rearrange all the other elements, just like the teddy bears in the first scenario. But if you use a linked list, all you need to do is change the reference of the first element of the sequence. The rest of the elements keep their existing positions and links.

When the elements of a linked list reference the next and previous elements, we call it a doubly-linked list. And since a linked list can be used to create a queue, a doubly-linked list can be used for a double-ended queue…

When you need a doubly-linked list in Python, you can use the deque data structure, which is in the collections module.

A Technical Appendix

I was tempted to end this post here, at the end of the picture story. I slipped in a few Python-specific sections amid the pictures and their captions to provide context. That’s enough, I thought.

But this is still a technical article. So let me add some Python code. I’ll keep this appendix brief. I’ll re-use code I published in my first ever self-published technical article about Python (and not one published on Real Python, which predate “my own” articles.) This was in July 2021.

Empty a list and a deque from the left

Let’s create a sequence of random numbers and store the numbers in a list and a deque:

There are a million numbers. You run loops to empty the list and the deque from the left—always removing the first number in the sequence. Here’s the output I get on my system. Performance on your system may vary:

Emptying a list from the left is very expensive, not so with a deque
(time to put the kettle on...)
Time to empty list from left: 78.19841980934143
Time to empty deque from left: 0.04054713249206543

It takes well over a minute to empty the list from the left but a fraction of a second to empty the deque. Recall that the list is analogous to the row of boxes with teddy bears. If you remove the first one, you have to take each of the remaining bears and move it to the previous box. Whereas when you remove the first item from a deque, you don’t need to visit all the other boxes.

This behaviour is what’s required in a queue. The item to take out from the list is the one that’s been there the longest—the first one.

Empty a list and a deque from the right

Let’s empty the same structures from the right instead:

There’s no difference in performance in this case:

However, emptying a list from the right is not expensive
Time to empty list from right: 0.03871321678161621
Time to empty deque from right: 0.03797125816345215

When you remove the last of the teddy bears from its box, you don’t need to move any of the others.

So is a deque always better?

No.

I won’t give a long discussion, I’ll just show one example. Let’s fetch the middle element from both structures. We’ll fetch this item a million times to get a meaningful time estimate for comparison:

Here’s the output:

But, fetching an item from the middle of a deque is expensive, unlike lists
Time to fetch middle element from list 1000000 times: 0.14912009239196777
(time to drink that tea you made earlier...)
Time to fetch middle element from deque 1000000 times: 45.576027154922485

In a list, it’s easy to find the middle box in the sequence as the boxes are all lined up next to each other. In a deque, you have to start from the beginning or the end of the sequence, it doesn’t matter which end since it’s a double-ended queue, and then go from one box to the next until you find the middle one. That’s slow.

Code in this article uses Python 3.11
